Wheelchair Ramps Folding 2ft-8ft

Lightweight folding wheelchair ramps that provide wheelchair access over any kerb or step. Choose from 2ft, 3ft, 4ft, 5ft, 6ft, 7ft and 8ft lengths. With weights starting at just over 5kg, this disabled access ramp/suitcase ramp can be easily folded length ways during transport, with or without the bag. Internal width 715mm and total width 720mm.

Wheelchair ramp bags available for ramps up to 5ft long.

Category: RAMPS

Description

Folding ramp design for easy storage and transport
Rest on connection – to fit just rest on and start loading
Maximum gradient = 1 in 6 although 1 in 8 is recommended
Lightweight for easy handling
Edges on each side of the suitcase ramp to prevent accidentally wheeling off
Edges is 30mm high
Not suitable for flight cases.

Folding Wheelchair Ramp Range

2ft

The 2ft with the new improved flat hinge
Length 2ft (610mm)
Weight 5.4kg
Capacity 300kg
Internal width 715mm
Max. load height 100mm

3ft

The 3ft with the new improved flat hinge
Length 3ft (915mm)
Weight 8.0kg
Capacity 300kg
Internal width 715mm
Max. load height 150mm

4ft

The 4ft with the new improved flat hinge
Length 4ft (1219mm)
Weight 10.4kg
Capacity 300kg
Internal width 715mm
Max. load height 200mm

5ft

The 5ft with the new improved flat hinge
Length 5ft (1524mm)
Weight 13.2kg
Capacity 300kg
Internal width 715mm
Max. load height 250mm

Capacity (kg)	275-300
Internal Width (mm)	715
Length (ft)	2 – 8
Length (mm)	610- 2440
Min Load Height (mm)	61
Total Width (mm)	720
Weight (kg)	5.4 – 23
Easy to Fit	Yes
Electric Wheelchair	Yes
Manual Wheelchair	Yes
Mobility Scooter Friendly	Yes
